| Classification |
Electric Characteristics |
| General |
Cooling Method |
Forced cooling |
| Rated Usage |
100% continuous |
| Inverter Control |
CR PWM |
| Output Port |
220Vac 2ball socket |
| Capacity(KVA) |
1 / 2 / 3 / 5 |
| Enclosure |
Rack Type & Stand alone |
| Input |
Rated Voltage |
24Vdc / 48Vdc |
| Range of Voltage |
19V - 27V / 40V - 56V |
Output
Voltage |
Phase |
1Ø2W / G |
| Rated Voltage |
110Vac, 220Vac (Selectable) |
| Rated Frequency |
60Hz ± 0.3Hz |
| Waveform Distortion |
3% (Total Harmonic Distotion) |
| Resistance to Overload |
1 minute at 120% of load, 10 seconds at 150% of load |
| Overall Efficiency |
83% or greater |
| Insulation |
Insulation Resistance |
5Moms or greater at DC 500V mega |
| Insulation Voltage |
No problem for 1 minute at AC 1500V 60Hz |
Temperature
Rising |
ICs |
80 DGE or lower |
| Transformers |
140 DGE or lower |
|
|
|
 |
|
